扇形噴霧噴嘴
噴霧角度（0.3Mpa壓力下）
120° 110° 95° 80° 65° 50° 45° 40° 35° 25° 15° 0° 備注：可按照客戶要求定制噴霧角度
流量代碼 鏈接螺紋 噴孔mm 流量（升/分）
1/8 1/4 3/8 1/2 0.05Mpa 0.1Mpa 0.15Mpa 0.2 Mpa 0.3 Mpa 0.4 Mpa 0.5 Mpa 0.6 Mpa 0.7 Mpa 1.0 Mpa 3.5Mpa
01
●
●
●
● 0.66
0.23 0.28 0.32 0.39 0.46 0.51 0.56 0.60 0.72 1.3
015
●
●
●
● 0.79
0.34 0.40 0.48 0.59 0.68 0.76 0.84 0.90 1.1 2.0
02
●
●
●
● 0.91
0.46 0.56 0.64 0.79 0.91 1.0 1.1 1.2 1.4 2.7
03
●
●
●
● 1.1 0.48 0.68 0.83 0.97 1.2 1.4 1.5 1.7 1.8 2.2 4.0
04
●
●
●
● 1.3 0.65 0.91 1.1 1.3 1.6 1.8 2.0 2.2 2.4 2.9 5.4
05
●
●
●
● 1.4 0.80 1.1 1.3 1.6 2.0 2.3 2.5 2.8 3.0 3.6 6.7
06
●
●
●
● 1.6 0.97 1.4 1.7 1.9 2.4 2.7 3.1 3.3 3.6 4.3 8.1
08
●
●
●
● 1.8 1.3 1.8 2.2 2.6 3.2 3.6 4.1 4.5 4.8 5.8 10.8
10
●
●
●
● 2.0 1.5 2.3 2.8 3.2 3.9 4.6 5.1 5.6 6.0 7.2 13.5
15
●
●
●
● 2.4 2.5 3.4 4.2 4.6 5.9 6.8 7.6 8.4 9.0 10.8 20
20
●
●
●
● 2.8 3.2 4.6 5.6 6.5 7.9 9.1 10.2 11.2 12.1 14.4 27
30
●
●
●
● 3.6 4.8 6.8 8.3 9.7 11.8 13.7 15.3 16.7 18.1 22 40
40
●
●
● 4.0 6.5 9.1 11.1 12.9 15.8 18.2 20 22 24 29 54
50
●
●
● 4.4 8.0 11.4 14.0 16.1 19.7 23 25 28 30 36 68
60
●
●
● 4.8 9.7 13.7 16.8 19.3 24 27 31 33 36 43 81
70
●
●
● 5.2 11.2 16 19.6 23 28 32 36 39 42 50 94
100
●
● 6.4 16.1 23 28.2 32 39 46 51 56 60 72 135
120
●
● 6.7 17.2 27 32 39 47 55 61 67 72 86 162
150
●
● 7.5 31 34 39 48 59 68 76 84 90 108 205
200
● 8.7 39 46 51 64 79 91 102 112 121 144 270
流量代碼 鏈接尺寸 孔徑mm 流量（升/分鐘） 噴流角度壓力Mpa 1/8 1/4 3/8 1/2 3/4 0.05 0.07 0.1 0.15 0.2 0.3 0.4 0.05 0.15 0.4 0.25
●
0.41
0.11 0.14 0.16 0.2 0.23
83° 117° 0.50
●
0.61
0.23 0.28 0.32 0.39 0.46
89° 122° 0.75
●
0.71
0.29 0.34 0.42 0.48 0.59 0.68
106° 125° 1
●
0.84
0.38 0.46 0.56 0.64 0.79 0.91
109° 128° 1.5
●
1.0 0.48 0.57 0.68 0.84 0.97 1.2 1.4 73° 108° 125° 2
●
●
1.2 0.64 0.76 0.91 1.1 1.3 1.6 1.8 83° 113° 129° 2.5
●
●
1.3 0.81 0.95 1.1 1.4 1.6 2.0 2.3 98° 122° 133° 3
●
●
1.4 0.97 1.1 1.4 1.7 1.9 2.4 2.7 86° 112° 126° 4
●
●
1.7 1.3 1.5 1.8 2.2 2.6 3.2 3.6 97° 123° 132° 5
●
●
1.9 1.6 1.9 2.3 2.8 3.2 3.9 4.6 114° 128° 142° 7.5
●
●
2.3 2.4 2.9 3.4 4.2 4.8 5.9 6.8 101° 119° 134° 10
●
●
2.6 3.2 3.8 4.6 5.6 6.4 7.9 9.1 115° 133° 145° 12
●
●
2.9 3.9 4.6 5.5 6.7 7.7 9.5 10.9 128° 139° 153° 15
●
●
3.3 4.8 5.7 6.8 8.4 9.7 11.8 13.7 98° 113° 123° 18
●
●
3.6 5.8 6.9 8.2 10 11.6 14.2 16.4 106° 120° 131° 20
●
●
3.8 6.4 7.6 9.1 11.2 12.9 15.8 18.2 110° 122° 133° 22
●
4.0 7.1 8.4 10 12.3 14.2 17.4 20 113° 125° 136° 24
●
4.1 7.7 9.2 10.9 13.4 15.5 18.9 22 115° 131° 144° 27
●
4.4 8.7 10.3 12.3 15.1 17.4 21 25 119° 135° 148° 30
●
4.6 9.7 11.4 13.7 16.7 19.3 24 27 100° 110° 121° 35
●
5.0 11.3 13.3 16 19.5 23 28 32 105° 118° 128° 40
●
●
5.3 12.9 15.3 18.2 22 26 32 36 111° 126° 136° 45
●
●
5.6 14.5 17.2 21 25 29 36 41 115° 130° 140° 50
●
6.0 16.1 19.1 23 28 32 39 46 117° 131° 140° 60
●
6.5 19.3 23 27 33 39 47 55 120° 134° 142° 70
●
7.1 23 27 32 39 45 55 64 123° 137° 146° 80
●
7.5 26 31 36 45 52 63 73 127° 138° 149° 90
● 8.0 29 34 41 50 58 71 82 120° 133° 140° 100
● 8.4 32 38 46 56 64 79 91 123° 136° 145° 110
● 8.8 35 42 50 61 71 87 100 125° 138° 148° 120
● 9.3 39 46 55 67 77 95 109 129° 143° 150° 140
● 10.3 45 53 64 78 90 111 128 118° 127° 135° 160
● 11.1 52 61 73 89 103 126 146 121° 130° 137° 180
● 11.5 58 69 82 100 116 142 164 124° 133° 139° 210
● 12.3 68 80 96 117 135 166 191 128° 139° 145° 300
● 14.7 97 114 137 167 193 235 275 110° 128° 135° 450
● 17.9 145 172 205 250 290 335 410 118° 132° 138° 流量大小
鏈接尺寸
噴孔mm
流量（升/分）
噴流角度
尺寸 1/8 1/4 3/8 1/2 3/4 1巴 2巴 3巴 4巴 5巴 6巴 7巴 10巴 1 巴 3巴 7巴
偏轉(zhuǎn)角度
棒材尺寸 5010
●
2.0 2.3 3.2 3.9 4.6 5.1 5.6 6.0 7.2 31° 50° 60° 60° 16 5020
● ●
2.8 5.7 8.1 9.9 11.4 12.7 14.0 15.1 18.0 42° 50° 59° 42° 19 5040
● ●
3.6 9.1 12.9 15.8 18.2 20 22 24 29 47° 50° 60° 45° 19 5060
●
4.8 13.7 19.3 24 27 31 33 36 43 55° 50° 53° 37° 25 50100
●
6.0 23 32 39 46 51 56 60 72 72° 50° 55° 40° 32 50125
●
6.7 28 40 49 57 64 70 75 90 72° 50° 59° 38° 32 50160
●
7.5 36 52 63 73 82 89 96 115 72° 50° 55° 37° 32 50200
●
8.3 46 64 79 91 102 112 121 144 72° 50° 55° 32° 22 4040
●
3.6 9.1 12.9 15.8 18.2 20 22 24 29 31° 40° 50° 35° 25 4050
●
4.0 11.4 16.1 19.7 23 25 28 30 36 31° 40° 49° 33° 25 4060
●
4.4 13.7 19.3 24 27 31 33 36 43 32° 40° 49° 33° 25 4070
●
5.2 16 23 28 32 36 39 42 50 32° 40° 49° 29° 25 4080
●
5.2 18.2 26 32 36 41 45 48 58 32° 40° 48° 26° 25 4090
●
5.6 21 29 36 41 46 50 54 65 34° 40° 44° 28° 25 40100
●
6.0 23 32 39 46 51 56 60 72 35° 40° 44° 28° 12 3504 ●
1.2 0.91 1.3 1.6 1.8 2.0 2.2 2.4 2.9 20° 35° 41° 40° 16 3510
●
2.0 2.3 3.2 3.9 4.6 5.1 5.6 6.0 7.2 18° 35° 39° 36° 19 3520
● ●
2.8 4.6 6.4 9.9 11.4 12.7 14.0 15.1 18.0 24° 35° 40° 30° 19 3530
●
3.2 6.8 9.7 11.8 13.7 15.3 16.7 18.1 22 24° 35° 39° 28° 19 3540
●
3.6 9.1 12.9 15.8 18.2 20 22 24 29 26° 35° 41° 26° 22 3550
●
4.0 11.4 16.1 19.7 23 25 28 30 36 28° 35° 38° 23° 22 3560
●
4.4 13.7 19.3 24 27 31 33 36 43 31° 35° 38° 27° 25 3580
●
5.2 18.2 26 32 36 41 45 48 58 29° 35° 39° 24° 25 35100
●
6.0 23 32 39 46 51 56 60 72 26° 35° 40° 19° 25 35160
● 7.5 36 52 63 73 82 89 96 115 26° 35° 40° 23° 32 35200
● 8.3 46 64 79 91 102 112 121 144 26° 35° 40° 22° 32 2540
●
3.6 9.1 12.9 15.8 18.2 20 22 24 29 15° 25° 34° 25° 19 1510
●
2.0 2.3 3.2 3.9 4.6 5.1 5.6 6.0 7.2
15° 23° 22° 16 1520
●
2.8 4.6 6.4 9.9 11.4 12.7 14.0 15.1 18.0
15° 19° 19° 16 1530
●
3.2 6.8 9.7 11.8 13.7 15.3 16.7 18.1 22 6° 15° 24° 25° 19 1540
●
3.6 9.1 12.9 15.8 18.2 20 22 24 29 8° 15° 21° 18° 22 1550
●
4.4 11.4 16.1 19.7 23 25 28 30 36 9° 15° 20° 15° 22 1560
●
4.8 13.7 19.3 24 27 31 33 36 43 10° 15° 19° 14° 25 1580
●
5.2 18.2 26 32 36 41 45 48 58 11° 15° 18° 14° 25 15100
●
6.0 23 32 39 46 51 56 60 72 11° 15° 18° 14° 25 15200
● 8.3 46 64 79 91 102 112 121 144 12° 15° 18° 14° 32 鏈接尺寸 噴射角度(0.5mpa下) 孔徑mm 流量（升/分鐘）壓力Mpa 3/8 3/4 1-1/4 20°，30°，45°，60°，75°，90°，120° 0.05Mpa 0.1 Mpa 0.2 Mpa 0.3 Mpa 0.5 Mpa 1 Mpa 噴嘴型號(hào)
●
FSUN-S-0.6 0.8 0.2 0.3 0.4 0.5 0.6 0.9
●
FSUN-S-1 1.0 0.3 0.5 0.6 0.8 1.0 1.4
●
FSUN-S-1.5 1.2 0.5 1.7 1.0 1.2 1.5 2.1
●
FSUN-S-2 1.4 0.6 0.9 1.3 1.6 2.0 2.8
●
FSUN-S-2.5 1.5 0.8 1.1 1.6 1.9 2.5 3.5
●
FSUN-S-3 1.7 1.0 1.3 1.9 2.3 3.0 4.2
●
FSUN-S-4 20 1.3 1.8 2.5 3.1 4.0 5.6
●
FSUN-S-5 2.2 1.5 2.2 3.2 3.9 5.0 7.1
●
FSUN-S-6 2.5 1.9 2.7 3.8 4.6 6.0 8.5
●
FSUN-S-7.5 2.7 2.4 3.4 4.7 5.8 7.5 10.6
●
●
FSUN-S-10 3.0 3.2 4.5 6.3 7.8 10.0 14.1
●
●
FSUN-S-13 3.5 4.1 5.8 8.2 10.1 13.0 18.4
●
●
FSUN-S-16 4.0 5.1 7.2 10.1 12.4 16.0 22.6
●
●
FSUN-S-20 4.5 6.3 8.9 12.7 15.5 20.0 28.3
●
●
FSUN-S-25 5.0 7.9 11.2 15.8 19.4 25.0 35.4
●
FSUN-S-32 5.5 10.1 14.3 20.2 24.8 30.0 45.3
●
FSUN-S-40 6.0 12.7 17.9 25.3 31.0 40.0 56.6
●
FSUN-S-50 7.0 15.8 22.4 31.6 38.7 50.0 70.7
●
● FSUN-S-63 8.0 19.9 28.2 39.8 48.8 63.0 89.1
●
● FSUN-S-80 9.0 25.3 35.8 50.6 62.0 80.0 113.1
●
● FSUN-S-100 10.0 31.6 44.7 63.2 77.5 100.0 141.1
●
● FSUN-S-130 11.0 41.4 58.1 82.2 100.7 130.0 183.8
●
● FSUN-S-160 12.0 50.0 71.6 101.2 123.9 160.0 226.3
●
● FSUN-S-200 13.0 63.2 89.4 126.5 154.9 200.0 282.8
●
● FSUN-S-250 15.0 79.1 111.8 158.1 193.7 250.0 353.6
